概述
Megapixel lens is essential to achieve high quality and full resolution of high definition cameras. Overall image quality is greatly affected by the quality of the optical lens. This lens provides high contrast, brightness and sharpness across the entire image plane. It is light, compact, CS mount, f1.6 apeture and fixed focal length from 2.8 to 8mm. From wide view angle to narrow view angle, other focal lens with narrower view angle is also available for custom order. The outstanding performance makes the lens fit many different type camera applications.
Hightlights
- 3 Megapixel designed for full HD camera
- CS Mount
- Durable metal barrel and mount
- Available from wide view angle to narrow view angle
- Fiexed focal with apeture f1.6
規格
| Fixed Focal Lens |
Pixels | 3 Mega |
| Focal Length(mm) | 2.1, 2.8, 3.6, 4, 6, 8 Other focal lens, fisheye lens, non-distortion lens are also optional |
|
| View Angle | D170ºxH130ºxV96º D115ºxH109ºxV90º D100ºxH76ºxV56º D90ºxH72ºxV54º D61ºxH48.8ºxV36.6º D46.2ºxH37ºxV27.7º |
|
| Aperture | f1.6 | |
| Mount | CS | |
| Iris | Fixed | |
| Focus | Manual | |
| Physical | Dimension(mm) | Φ33×17.64, Φ30×17.6, Φ30×20.8, Φ30×19, Φ30×22.5, Φ30×19.6 |
| Weight(g) | 28, 28, 26, 32, 30, 27 |
下載
訂單信息
| Item | P/N |
| 2.1mm CS lens, F1.8, 3MP | 57025-021 |
| 2.8mm CS lens, F1.8, 3MP | 57025-028 |
| 3.6mm CS lens, F1.8, 3MP | 57025-036 |
| 4 mm CS lens, F1.6, 3MP | 57025-040 |
| 6 mm CS lens, F1.6, 3MP | 57025-061 |
| 8 mm CS lens, F1.6, 3MP | 57025-080 |
| C/CS Mount Adapter Ring | 57039 |
